IE2 MS801-2 0.75KW/1HP Three Phase Electric Motor

Name: IE2 MS801-2 0.75KW/1HP Three Phase Electric Motor
Brand: ZOZHI
SKU: 103937
Price: 46.4 USD
Availability: InStock

0 customer reviews {{parseInt(detail_data.left_num) ? 'In Stock.' :detail_data.zeroStockOrder==0?'Out of Stock':'Available'}} SKU.103937

: {{detail_data.prodInfo.name}}

{{comment.count}} Reviews Request Quote

{{ detail_data.displayed_price.unit_prefix }} {{ detail_data.displayed_price.value }}
{{parseInt(detail_data.left_num) ? detail_data.left_num +' In Stock' :detail_data.zeroStockOrder==0?'Out of Stock':'Available'}}

Description
Specification
Download
Questions & Answers
Customer Reviews

$ 46.4

0Reviews

{{ detail_data.displayed_price.unit_prefix }} {{ detail_data.displayed_price.value }} {{detail_data.displayed_price.ex_sell_type}}

{{ item.num }} pieces

$ {{ item.price }}

{{item.name}}* {{item.values[0].value}}: {{sku.value}}

Quantity:

{{detail_data.displayed_price.unit_type_name}}(s)

( Min. Order {{detail_data.prodInfo.minimum_ordered_quantity}} )

Shipping:

Free Shipping

Can't deliver

To Be Negotiated

to United States Change

Estimated delivery time : {{now_chooseship?now_chooseship.datemin:''}}-{{now_chooseship?now_chooseship.datemax:''}} working days. See details

Total Price:

$ 46.4 ~~$ 0.00~~

Shipping calculated at checkout.

Weight:

{{Number(packInfo.weight).toFixed(2)}} KG

Package:

{{packInfo.length}}cm*{{packInfo.width}}cm*{{packInfo.height}}cm

Returns:

Read details

Add to Wish list

You May Also Like

Description
Description
Specification
Download
Customer Reviews
Questions & Answers

Description

Output Range: 0.75KW
Voltage:230/400V
Frequency: 50Hz/60Hz/as required
No. of Poles: 2
Speed: 2800rpm
Protection class: IP44 / IP54 / IP55
Insulation class: B / F
Connection: Y/D
Altitude: less than 1000 meter
Working temperature: -15°C~40°C
Duty type: S1
Cooling method: IC411

Mounting styles: B3 / B5 / B35

*B3 Frame with foot end, shield without flange

*B35 Frame with foot end, shield with flange
*B5 Frame without foot end, shield with flange.workshop

Features of 3 phase asynchronous induction motor	Self-starting, Robust in construction
	Economical, Easier to maintain.
	Less armature reaction and brush sparking because of the absence of commutators and brushes that may cause sparks.

IE2 MS801-2 0.75KW/1HP Three Phase Electric Motor

Technical Data

Model	Power		(V)	(A)	(r/min)	Eff.(%)			P.F.	Ist/In	Tmax/Tn
Model	Kw	HP	(V)	(A)	(r/min)	50%	75%	100%	P.F.	Ist/In	Tmax/Tn
IE2 MS801-2	0.75	1	230/400	3.0/1.73	2800	76.5	77.3	77.4	0.813	2.2	2.3
IE2 MS802-2	1.1	1.5		4.2/2.43	2800	79.0	80.0	79.6	0.825	2.2	2.3
IE2 MS90S-2	1.5	2		5.53/3.19	2820	80.2	81.5	81.3	0.837	2.2	2.3
IE2 MS90L-2	2.2	3		7.93/4.58	2820	82.2	83.5	83.2	0.837	2.2	2.3
IE2 MS100L-2	3	4		10.5/6.06	2830	84.0	85.1	84.6	0.848	2.2	2.3
IE2 MS112M-2	4	5.5	400/690	7.97/4.6	2850	85.4	86.8	85.8	0.848	2.2	2.3
IE2 MS132S1-2	5.5	7.5		10.65/6.15	2870	86.7	87.3	87.0	0.860	2	2.3
IE2 MS132S2-2	7.5	10		14.35/8.28	2870	87.6	88.3	88.1	0.860	2	2.3
IE2 MS160M1-2	11	15		20.74/11.97	2900	89.0	89.8	89.4	0.860	2	2.3
IE2 MS160M2-2	15	20		27.99/16.16	2900	90.0	90.5	90.3	0.860	2	2.3
IE2 MS160L-2	18.5	25		33.83/19.53	2900	90.3	91.0	90.9	0.872	2	2.2
IE2 MS802-4	0.75	1	230/400	3.28/1.9	1380	77.3	79.8	79.6	0.720	2.3	2.3
IE2 MS90S-4	1.1	1.5		4.57/2.64	1400	79.9	81.7	81.4	0.743	2.3	2.3
IE2 MS90L-4	1.5	2		6.02/3.48	1400	82.1	83.5	82.8	0.755	2.3	2.3
IE2 MS100L1-4	2.2	3		8.42/4.86	1420	82.6	84.5	84.3	0.778	2.2	2.3
IE2 MS100L2-4	3	4		11.32/6.54	1420	84.2	85.7	85.5	0.778	2.2	2.3
IE2 MS112M-4	4	5.5	400/690	8.47/4.89	1430	85.8	87.0	86.6	0.790	2.2	2.3
IE2 MS132S-4	5.5	7.5		11.18/6.45	1450	87.4	88.3	87.7	0.813	2.2	2.3
IE2 MS132M-4	7.5	10		14.85/8.58	1450	88.2	89.0	88.7	0.825	2.2	2.3
IE2 MS160M-4	11	15		21.84/12.61	1460	89.1	90.0	89.8	0.813	2.2	2.3
IE2 MS160L-4	15	20		29.08/16.79	1460	90.2	91.1	90.6	0.825	2.2	2.3
IE2 MS90S-6	0.75	1	230/400	3.82/2.2	910	73.4	76.3	75.9	0.650	2	2.2
IE2 MS90L-6	1.1	1.5		5.25/3.03	910	77.0	78.8	78.1	0.673	2	2.2
IE2 MS100L-6	1.5	2		6.77/3.91	940	79.6	80.8	79.8	0.697	2	2.2
IE2 MS112M-6	2.2	3		9.69/5.59	940	80.4	81.6	81.8	0.697	2	2.2
IE2 MS132S-6	3	4		12.56/7.25	960	81.0	83.4	83.3	0.720	2	2.2
IE2 MS132M1-6	4	5.5	400/690	9.36/5.4	960	82.7	84.5	84.6	0.732	2	2.2
IE2 MS132M2-6	5.5	7.5		12.47/7.2	960	84.8	86.2	86.0	0.743	2	2.2
IE2 MS160M-6	7.5	10		16.78/9.69	970	86.4	87.5	87.2	0.743	2	2
IE2 MS160L-6	11	15		24.19/13.97	970	88.2	89.2	88.7	0.743	2	2

B5R 4 Holes at 45'
TYPE	P	N	M	S	T
80	160	110	130	10	3.5
90	160	110	130	10	3.5
100	200	130	165	12	3.5
112	200	130	165	12	3.5
132	250	180	215	15	4.0

B14B 4 Holes at 45'
TYPE	P	N	M	S	T
80	160	110	130	M8	3.5
90	160	110	130	M8	3.5
100	200	130	165	M10	3.5
112	200	130	165	M10	3.5
132	250	180	215	M12	4.0

Specification

Model IE2 MS802-2
Rate Power 0.75kw/1Hp
Pole 2
G W 9.6KGS
Weight 9.6 kg
Package 33.00cm*19.00cm*21.50cm
