Description

Product Name:	Replacement Generator Automatic voltage regulator Stamford AVR AS440
Sending/Power input	Voltage	Jumper selectable 100-130V ac 1 phase or 190-264V ac 1 phase
	Frequency	50-60 Hz nominal
Output	Voltage	82V dc @ 200V ac
	Current	Continuous 4A,transient 7.5A for 10 secs
Voltage Regulation	< +/-1% (with 4% engine governing)

AS440 is a half-wave phase-controlled thyristor type AVR and forms part of the excitation system for a brushless generator. the design employs Surface Mount Technology (SMT) for high integration of features in a small footprint AVR.

Advantage:

Fireproof and heat-insulating soft rubber compared to ordinary soft rubber, we reach the military level.
High-temperature resistant shell, no deformation in a high-temperature environment, no cracking.
EPCOS capacitor has good temperature stability and high precision
High-quality capacitance, good parameter consistency, and high reliability.

MODEL	SENSING INPUT	POWER INPUT	MAGNETIC FIELDOUTPUT		PRESSURE REGULATING ACCURACY
			Voltage(max)	Current(within 10 sec)	with 4% rngine governing

SX460	120(95-132VAC)240(190-264VAC),1phase,2wire, with copper jumper options		90VAD at 207VAC	continuous 4A,intermittent 10A	<±1%RMS
SX460-A
SX440	190-264VAC,1phase,2wire.
SX440-A
AS440	120(95-132VAC)240(190-264VAC),1phase,2wire, with copper jumper options
AS480
MX341	190-264VAC, 1phase,2wire	170-220VAC, 3Phase,3wire	120VAD	continuous 2.7A,intermittent 6A	<±0.5%RMS
MX321	190-264VAC, 2phase,3wire		120VAD	continuous 3.7A,intermittent 6A
MX450	170-264VAC,1phase,2wire		90VAD	continuous 4A,intermittent	<±1%RMS

How to choose Stanford Generator AVR
Generator/AVR	SA465	SA465	SX460	SX440	SX421	MS341	MX321
BC16			STD
BC16			STD
BC182			STD
BC184	AUX WDG	OPT	STD		LOOSE
UC224			STD	OPT	OPT	OPT(PMG)	OPT(PMG)
UC274			STD	OPT	OPT	OPT(PMG)	OPT(PMG)
HC4				STD	OPT	OPT(PMG)	OPT(PMG)
HC5				STD	OPT	OPT(PMG)	OPT(PMG)
HC6							STD
HC/MV7							STD

Specification

Model Number AS440
Phase Three Phase, three phase and single phase
Current Type AC
Function For generator avr
GUM type Hard Gum, Soft for option
Capacitor Color Blue Capacitor, Red for option
Quality Class A class high quality
Stock Stock supply for AVR AS440
Certificate CE,RoHS,ISO9001
Warranty 1 year
Weight 0.47 kg
